Air Filter | Standard Kawasaki Air Cleaner |
---|---|
Anti Scalp Wheels | 3 Standard |
Armrests | Optional |
Bagger Capacity | 4.9 bushels |
Blade Tip Speed | 18,500 ft/min / 5,638 m/min |
Box Dimensions | 82.0 in. x 63.0 in. x 35.0 in. / 208.3 cm x 160.0 cm x 88.9 cm |
CARB Compliant | Not CARB Compliant |
Carrier Frame | 3 in. x 1.5 in. x 0.120 in. (7.6 cm x 3.8 cm x 0.3 cm) Wall Tubular Steel |
Caster Tires | 13 in. x 6.5 in. – 6 in. (33 x 16.5 cm – 15.2 cm) Pneumatic |
Clutch | Electromagnetic |
Comfort Platform | Standard Suspension |
Cooling System | Air Cooled |
Crankshaft | 1″ (25 mm) w/Steel Protector |
Cup Holder | Standard |
Cutter System | Steel Cutting Blade |
Deck Design | 10-Gauge steel IrongForged® |
Deck Material | 10 Gauge Steel |
Deck Size | 60 in / 152 cm |
Discharge Chute | Side |
Drive System | Hydrostatic |
Drive Tires | 20 in. x 10 in. – 8 in (51 cm x 26 cm – 20.3 cm) |
Drive Type | Rear-Wheel Drive |
Engine | 23 hp Kawasaki FR691V 726cc |
Engine Brand | Kawasaki |
Engine Displacement (cc) | 726 cc |
Engine Horsepower | 23.0 hp |
Engine Power (kW) | 17.2 kW |
Foot Operated Height of Cut | Standard |
Forward Ground/Transport Speed | Up to 7.0 mph / 11.2 kph |
Forward Mowing Speed | Up to 7.0 mph / 11.2 kph |
Frame | 3 in. x 1.5 in. (7.6 cm x 3.8 cm) Steel Tubing |
Fuel Capacity | 5 gal. / 18.9 L / 20 Qt. |
Fuel Type | Gasoline |
Greasable Bearings | Yes |
Height of Cut | 1.0 – 5.0 in. / 2.5 – 12.7 cm |
Hitch Bracket | Standard |
Hour Meter | Standard Hour Meter |
Hydraulic Drive | Standard |
Lighting | Optional |
Number of Blades | 3 |
Product Type | TimeCutter Max |
Product Use | Residential |
Recommended Oil Type | 10W-30 |
Roll-Over Protection (ROPS) | Optional |
Seat | 19″ Gaming Style |
Spindle Bearings | Maintenance-free |
Spindle Housing | Cast-Aluminum |
Start Type | Electric |
Steering Controls | Twin Lever |
Steering Dampeners | Standard Dampers |
Terrain Type | Flat with Obstacles |
Tires | 13 in. x 6.5 in. (33 cm x 16.5 cm) Front, 20 in. x 11 in. (50.8 cm x 27.9 cm) Rear |
Transmission | Dual Hydrostatic HG-ZT2800 |
Washout Port | Standard |
